VertexRSI 7.2m DBS-band Satellite Antenna with motorized Pedestal Mount & de-icing

Condition:Used and refurbished
Model:7.2KPK
Manufacturer:VertexRSI

VertexRSI 7.2m DBS-band Satellite Antenna, 4-port Ku-band with motorized Pedestal Mount and full reflector de-icing

The Vertex (VertexRSI) 7.2m KPK Cassegrain Earth Station Antenna is configured in DBS-band, 4-port Rx/Tx and includes a Motorized Kingpost Pedestal Mount with AZ/EL jackscrews, a Hub enclosure 178cm (70inch), 91cm (36inch) depth and 16-piece precision-formed aluminum panels with heat-diffusing white paint.

VertexRSI developed the 7.2m C-band and Ku-band antennas to offer superior performance for Rx-only and Rx/Tx worldwide applications. The Model 7.2KXC (C-band) and 7.2KXK (Ku-band) antennas incorporate stretch formed, doubly contoured panels with matched radials and hub assemblies for ease of field assembly. The reflectors and Azimuth/Elevation kingpost pedestals provide the stiffness and pointing accuracy required for C-band and Ku-band operation. These antennas are designed for full orbital arc coverage and are readily adaptable to ground or rooftop installations.


Options

  • Motorization Drive Systems and Tracking packages (USED as well as NEW)
  • Turnkey installations or installation assistance
  • Foundation Kit with Template

This VertexRSI 7.2m DBS-band Satellite Antenna System will be reconditioned and refinished to look and perform like new. We complete the antenna with refurbished motors and gearboxes, new limits, reflector hardware kits are checked out and a documentation package and foundation plans are provided. System is guaranteed to meet OEM specs when properly installed by our professional installation team.

This antenna system is originally DBS-band. You can opt for a turn-key installation solution. Our team has delivered and installed an identical VertexRSI 7.2m Earth Station Antenna in C-band at Hellas-Sat on Cyprus and a refurbished VertexRSI 7.2m Earth Station antenna in Ku-band in Qaanaaq, the northernmost town in Greenland for Tele Post (Tusass) in Greenland.  Please ask us for details!

This antenna will be de-installed in Europe in Q2 2025 and has the original VertexRSI de-icing enclosure included that will be fully refurbished as well.

Our professional installation team can support you with full installation, panel adjustment and tests. Please feel free to request more information.
